Lilac plain aluminum Venetian blind (Product Code: P130)

The aluminum Venetian blind is made from 16 mm or 25 mm wide aluminum slats with a thickness of 23 microns, coated in lilac using electrostatic powder paint. The slats are shaped by a fully automatic Venetian blind machine. For better alignment, the bottom rail, made of steel and also powder-coated, is attached. A control mechanism called “duck” is installed in the top rail to operate the blind. A polycarbonate tilt rod, adjusted according to the blind’s height, is attached to the control mechanism. By using this rod, you can adjust the direction of the slats and control light entering the room. A locking mechanism is also installed next to the control system, allowing the blind to be raised or lowered via cords. When deciding on the control side, consider whether the control and lock mechanism should be on the left or right when facing the blind, to prevent interference with doors or windows when raised.

Technical Specifications

• Top and bottom rail thickness: Standard for 16 mm and 25 mm slats

• Top rail height and width: 25 mm

• Bottom rail height: 11 mm, width: 19 mm

Blind Stack Height

16 mm & 25 mm Aluminum Venetian Blind Features

• 16 mm Slat Width: 16 mm

• 25 mm Slat Thickness: 0.22 µm

• Top Rail Width: 25 mm

• Top Rail Height: 24 mm

• “C” Type Bottom Rail Width: 19.5 mm

• “C” Type Bottom Rail Height: 10 mm

• Max Recommended Width (16 mm slat): 2600 mm

• Max Recommended Width (25 mm slat): 3000 mm

• Max Recommended Drop (16 mm slat): 2200 mm

• Max Recommended Drop (25 mm slat): 2600 mm

• Max Area (16 mm slat): 3.6 m²

• Max Area (25 mm slat): 4.5 m²

• Minimum Width (16 & 25 mm slat): 300 mm (single tilt & pull cord)

• Ladder Interval (16 mm slat): 40 cm

• Ladder Interval (25 mm slat): Max 45 cm

• Bottom Rail: High-strength vinyl-coated aluminum

• Top Rail: High-strength vinyl-coated aluminum

• Slats: High-strength vinyl-coated aluminum

• Cord Lock Mechanism: Molded plastic & metal

• Internal Components: Molded plastic

• Tassels & tilt rod caps: Molded plastic

• Tilt Mechanism: Molded plastic

• Brackets: Zinc-plated metal, coated

• Tilt Shaft: Steel “D” shape

• Cords: Colored 1.4 mm polyester threads

• Ladder (16 mm): Colored (13x18x2) mm polyester threads

• Ladder (25 mm): Colored (21.5x28x2) mm polyester threads

Choosing the Lilac Color

Lilac symbolizes solitude, leadership, wisdom, trust, and loyalty. Using lilac in professional environments can convey determination and commitment. It is one of the most popular colors, but when associated with food, care is advised, as lilac can suppress appetite and may have a slightly off-putting effect. Lilac can calm the nervous system and, unlike red, helps the mind relax and focus. Lighter lilac shades are ideal for peaceful bedrooms, promoting relaxation and a tranquil atmosphere. However, darker lilac tones can feel cold or depressing. Research shows that lilac environments can enhance concentration, learning, and physical performance.
